FlexScan® Business Monitors

From the workplace to your home office, EIZO provides business monitor solutions that are friendly to users and the environment.

Read moreShow less
Description

EIZO FlexScan® Premium Series

Both performance and environmental consciousness are important in today's society.

FlexScan combines cutting-edge technology with sustainable design to achieve the ideal in workstyle innovation. Whether it be in the office or at home, FlexScan enables business professionals to achieve comfort and efficiency while staying kind to the environment. FlexScan products come with a 5 years warranty, a testament to their longevity as a Made-in-Japan product.

EIZO FlexScan features the free Screen InStyle screen management software which streamlines screen management of single and multi-monitor environments for a better working environment. Some features include: Custom desktop layouts for multitasking, Adjusting display settings over multiple screens, and Saving display preferences for when you work at a hot-desking or shared workspaces environment.

Equipped with features such as a dedicated LAN port for laptops without it, Daisy Chaining multiple monitors for an even cleaner office aesthetic, and Eye Care and Ergonomics features. FlexScan is for the user who demands the most of their equipment.

To find out more, contact us at sales@oriens-group.com

Key Specifications (scroll right for more models):

EV3895EV3240XEV2740XEV2781EV2495EV2456
EIZO_APAC_FlexScan_EV3895_transparent.png EIZO_APAC_FlexScan_EV2495_1.png
Panel Specs
Size 37.5" (95.3 cm) 31.5" (80.0 cm) 27.0" (68.5 cm) 27.0" (68.5 cm) 24.1" (61.1 cm) 24.1" (61.1 cm)
Native Resolution 3840 x 1600 (24:10 aspect ratio) 3840 x 2160 (16:9 aspect ratio) 2560 x 1440 (16:9 aspect ratio) 3840 x 2160 (16:9 aspect ratio) 1920 x 1200 (16:10 aspect ratio) 1920 x 1200 (16:10 aspect ratio)
Pixel Pitch / Pixel Density 0.229 x 0.229 mm / 111 ppi 0.182 x 0.182 mm / 140 ppi 0.233 x 0.233 mm / 109 ppi 0.155 x 0.155 mm / 163 ppi 0.270 x 0.270 mm / 94 ppi 0.270 x 0.270 mm / 94 ppi
Brightness (typ.) 300 cd/m² 350 cd/m² 350 cd/m² 350 cd/m² 350 cd/m² 350 cd/m²
Contrast Ratio (typ.) 1000:1 2000:1 1000:1 2000:1 1000:1 1000:1
Video Signals
Video Input Terminals
  • USB Type-C (DisplayPort Alt Mode, HDCP 1.3)
  • DisplayPort (HDCP 1.3)
  • HDMI (HDCP 2.2 / 1.4) x 2
  • USB Type-C (DisplayPort Alt Mode, HDCP 2.3 / 1.3)
  • DisplayPort (HDCP 2.3 / 1.3)
  • HDMI (HDCP 2.3 / 1.4) x 2
  • USB Type-C (DisplayPort Alt Mode, HDCP 1.3)
  • DisplayPort (HDCP 1.3)
  • HDMI (HDCP 1.4)
  • USB Type-C (DisplayPort Alt Mode, HDCP 2.3 / 1.3)
  • DisplayPort (HDCP 2.3 / 1.3)
  • HDMI (HDCP 2.3 / 1.4) x 2
  • USB Type-C (DisplayPort Alt Mode, HDCP 1.3)
  • DisplayPort (HDCP 1.3)
  • HDMI (HDCP 1.4)
  • DisplayPort (HDCP 1.3)
  • HDMI (HDCP 1.4)
  • DVI-D (HDCP 1.4)
  • D-Sub mini 15 pin
USB
USB Upstream
  • USB 5Gbps: Type-B x 2
  • USB 5Gbps: Type-C (DisplayPort Alt Mode, Power Delivery Source 85 W max)
  • USB 5Gbps: Type-B
  • USB 5Gbps: Type-C (DisplayPort Alt Mode, Power Delivery Source 94 W max)
  • USB 5Gbps: Type-C (DisplayPort Alt Mode, Power Delivery Source 70 W max)
  • USB 5Gbps: Type-B
  • USB 5Gbps: Type-C (DisplayPort Alt Mode, Power Delivery Source 94 W max)
  • USB 5Gbps: Type-B
  • USB 5Gbps: Type-C (DisplayPort Alt Mode, Power Delivery Source 70 W max)
  • USB 5Gbps: Type-B
USB Downstream
  • USB 5Gbps: Type-A x 4
  • USB 5Gbps: Type-A x 3
  • USB 5Gbps: Type-C (Type-C Current, 15 W max)
  • USB 5Gbps: Type-A x 4
  • USB 5Gbps: Type-A x 3
  • USB 5Gbps: Type-C (Type-C Current, 15 W max)
  • USB 5Gbps: Type-A x 3
  • USB 5Gbps: Type-C (DisplayPort Alt Mode, Power Delivery Source 15 W max)
  • USB 5Gbps: Type-A x 2
USB LAN Adapter RJ-45 (1000BASE-T)
Windows 11, Windows 10 (64-bit, 32-bit), macOS Sierra (10.12) or later
RJ-45 (1000BASE-T)
Windows 11, Windows 10 (64-bit, 32-bit), macOS Sierra (10.12) or later
- RJ-45 (1000BASE-T)
Windows 11, Windows 10 (64-bit, 32-bit), macOS Sierra (10.12) or later
RJ-45 (1000BASE-T)
Windows 11, Windows 10 (64-bit, 32-bit), macOS Sierra (10.12) or later
-
Audio
Speakers 1.0 W + 1.0 W 2.0 W + 2.0 W 1.0 W + 1.0 W 2.0 W + 2.0 W 1.0 W + 1.0 W 1.0 W + 1.0 W
Audio Output Terminals
  • Headphones (Stereo mini jack)
  • Headphones (Stereo mini jack)
  • Line out (Stereo mini jack)
  • Headphones (Stereo mini jack)
  • Headphones (Stereo mini jack)
  • Line out (Stereo mini jack)
  • Headphones (Stereo mini jack)
  • Headphones (Stereo mini jack)
Power
Power Input AC 100 - 240 V, 50 / 60 Hz AC 100 - 240 V, 50 / 60 Hz AC 100 - 240 V, 50 / 60 Hz AC 100 - 240 V, 50 / 60 Hz AC 100 - 240 V, 50 / 60 Hz AC 100 - 240 V, 50 / 60 Hz
Typical Power Consumption 28 W 18 W 18 W 16 W 11 W 11 W
Power Save Mode 0.5 W or less 0.35 W 0.5 W or less 0.35 W 0.5 W or less 0.5 W or less
Physical Specs
Dimensions
(Landscape, W x H x D)
893.9 x 411 - 603.7 x 240 mm 712.2 x 427.3 - 622.2 x
242.4 - 250.7mm
611.4 x 368.6 - 545.2 x 230 mm 611.6 x 370.8 - 565.4 x
242 - 250.1 mm
531 x 356.2 - 538.4 x 230 mm 531 x 351.4 - 510.1 x 190 mm
Dimensions
(Without Stand, W × H × D)
893.9 x 398.2 x 109.8 mm 712.2 x 415.3 x 59 mm 611.4 x 356.6 x 56 mm 611.6 x 358.8 x 60.5 mm 531 x 344.2 x 53.7 mm 531 x 341.9 x 45.5 mm
Net Weight 13.2 kg 9.4 kg 8.5 kg 8.2 kg 7.6 kg 5.7 kg
Net Weight (Without Stand) 9.5 kg 6.7 kg 5.7 kg 5.5 kg 4.9 kg 3.7 kg
Height Adjustment Range 192.7 mm 195 mm 176.6 mm 195 mm 182.2 mm 158.6 mm
Tilt / Swivel 35° Up, 5° Down / 70° 35° Up, 5° Down / 90° 35° Up, 5° Down / 344° 35° Up, 5° Down / 90° 35° Up, 5° Down / 344° 35° Up, 5° Down / 344°
Pivot - 90° (clockwise) 90° (both clockwise and counter clockwise) 90° (clockwise) 90° (both clockwise and counter clockwise) 90° (both clockwise and counter clockwise)
Mounting Hole Spacing (VESA Standard) 100 x 100 mm 100 x 100 mm 100 x 100 mm 100 x 100 mm 100 x 100 mm 100 x 100 mm
Warranty
Warranty¹ 5 Years 5 Years 5 Years 5 Years 5 Years 5 Years
Zero Bright Pixels² Yes Yes Yes Yes Yes Yes

¹ Usage time is limited to 30,000 hours.  ² 6 months from the date of purchase.
