Large Diameter Slip Rings

Large diameter slip rings represent the union of manufacturing processes and technologies that enable Moog to offer large, high volume slip rings with advanced features that are cost effective. The manufacturing processes allow the slip ring to be built in an assembly line fashion that significantly reduces delivery time and price.

Features

• Platter or drum configuration
• Diameters exceeding 70 inches (1.7 m)
• Rotational speeds to 300 rpm
• Power rings rated up to 1000 V
• Power rings rated up to 300 amp
• Quiet mechanical system operation
• Low maintenance requirements
• Multiple brush tip options with minimal debris
• Capability of adding integral encoder, multiplexer, fiber optic rotary joint and non-contacting data link
• Multiplexing: multiple bidirectional signals to minimize ring count
• Encoder: capable of >15,000 counts
